Name: Zero distortion USB Camera Module 720P 1080P 30fps 8MP 4K 15FPS Hd MJPEG Mini CCTV Linux UVC Webcam Mini Surveillance camera
Brand: Mini USB Camera Mini Camera IP Camera Camhi Camera Factory
SKU: 3256801453482400
Price: 26.27 USD
Availability: InStock

Description

Zero distortion USB Camera Module 720P 1080P 30fps 8MP 4K 15FPS Hd MJPEG Mini CCTV Linux UVC Webcam Mini Surveillance camera

NOTE: Before purchasing this camera, please confirm whether your phone supports OTG function to avoid unnecessary losses

(For those who require OTG Micro USB interface, please contact customer service or note in your order,Thank you !)

Note: 2MP 1080P with audio,withZero distortion Lens ( type-c and micro usb cable length is 1meters)

1MP Without audio withZero distortion Lens ( type-c and micro usb cable length is 1meters)

if you need the cable longer or shorter ,pls send us message to custom made !

for more products infomation ,pls go to our store page !

if you have other requirement ,welcome contact with us free !

This camera is a 1.0Megapixel 1280*720p /5.0megapixel size 2592*1944P HD/2.0 megapixel size 1920*1080 pixel 1080P HD USB-2.0-free drive camera module, frame rate up to 30 frames. It can be used for one computer, advertising equipment, video doorbell, can meet the high demands of customers!

Feature:

HD 720P1080P/8MP USB camera module

Synchronization technology

High speed USB 2.0 interface

High quality image

Low power consumption

Small outline for embedded application

UVC compliance for use in OS Windows,Linux,Android,Mac

Typical application

1: ATM,Kiosk,POS,TV box2: advertising cameras3: one camera4: Smart TV built-in camera

5: Construction Equipment6: Banking equipment7: body switch8: Scanner

9: a mobile terminal device10: Medical diagnostic image acquisition11: fingerprints, palm prints image acquisition

12:video door phone13:HD surveillance

Remarks:

1: Use the USB cable wire into the computer, notebooks and other USB interface will be able to use!

2: inserted as computers, laptops can not be used, indicating that there is no drive in accordance with the camera.

3: This product is equipped with a USB cable.

Parameter description:

SLens Size:1/4 inch/1/2.7 inch /1/4 inch

Pixel size: 3um

Maximum effective pixels: 1280X720P /1920 (H) X1080 (V)/264(H) X 2448(V) 800MP pixels

Output image format: YUV2 (YUYV) / MJPEG

Frame rate:640X480 @ 30fps MJPEG,1280X720 @ 30fps MJPEG,1920X1080 @ 30fps MJPEG

YUV2,640X480 @ 20fps YUV2,1280X720 @ 5fps YUV2,1920X1080 @ 5fps YUV2 2592*1944P @15FPS 264(H) X 2448(V) 800MP pixels

Signal to noise ratio: 60dB

Dynamic range: 69dB

Sensitivity: 3.3V/lux-sec@550nm

Minimum illumination: 0.01LUX

Shutter type: Electronic rolling Frame shutter/ exposure

Interface type: USB2.0 High Speed

Support free flooding protocol: USB Video Class (UVC)

Support OTG protocol: USB2.0 OTG

Automatic exposure control AEC: support

Automatic white balance AEB: support

Automatic gain control AGC: support

Adjustable parameters: brightness contrast color saturation hue resolution

The gamma exposure contrast gain white balance backlighting

Power supply: USB BUS 4P-2.0mm POWER socket

Working voltage: DC5V

Working current: 140mA~220mA

Working temperature: 0 ~ 60

Storage temperature: -20 ~ 70 C

Board size: 15X15mm

Machine weight: 50g

Supported system: WinXP/Vista/Win7/Win8/Linux with UVC (above linux-2.6.26)/MAC-OS X 10.4.8 or later

/Wince with UVC/Android 4 or with above UVC

Lens: 5MP 3.6MM

Angle: 90degrees IN 1080P MODELS

Line length:3M usb 2.0Cable for 1080p 720p models

Package contents:

1 x Camera
