1.7mm Fisheye FOV 160Degree Without Black Corner Full HD Micro 1080P USB Camera Mini UVC Protocal 1920X1080P 2MP Mini PC Webcam Support OTG

Description

FOV 160Degree Without Black Corner Full HD Micro 1080P USB Camera Mini UVC Protocal 1920X1080P 2MP Mini PC Webcam Support OTG

Note: 1080P with audio,3Meters usb cable , the video display in the link is 1.7mm lens 2mp

if you need other connector ,pls kindly contact with us for custom made !

if you have other requirement ,welcome contact with us free !

real effect !!!

These interfaces are optional, please place orders which one you need:

This camera is a 2.0 megapixel size 1920*1080 pixel 1080P HD USB-2.0-free drive camera module, frame rate up to 30 frames. It can be used for one computer, advertising equipment, video doorbell, can meet the high demands of customers!

Feature:

HD 1080P USB camera module

Synchronization technology

High speed USB 2.0 interface

High quality image

Low power consumption

Small outline for embedded application

UVC compliance for use in OS Windows,Linux,Android,Mac

Typical application

1: ATM,Kiosk,POS,TV box2: advertising cameras3: one camera4: Smart TV built-in camera

5: Construction Equipment6: Banking equipment7: body switch8: Scanner

9: a mobile terminal device10: Medical diagnostic image acquisition11: fingerprints, palm prints image acquisition

12:video door phone13:HD surveillance

Remarks:

1: Use the USB cable wire into the computer, notebooks and other USB interface will be able to use!

2: inserted as computers, laptops can not be used, indicating that there is no drive in accordance with the camera.

3: This product is equipped with a USB cable.

Typical application

1: ATM,Kiosk,POS,TV box 2: advertising cameras 3: one camera 4: Smart TV built-in camera

5: Construction Equipment 6: Banking equipment 7: body switch 8: Scanner

9: a mobile terminal device 10: Medical diagnostic image acquisition 11: fingerprints, palm prints image acquisition

12:video door phone 13:HD surveillance

Parameter description:
Models:GS-15CM-1.7

SLens Size:1/2.7 inch

Pixel size: 3um

Maximum effective pixels: 1920 (H) X1080 (V)

Output image format: YUV2 (YUYV) / MJPEG

Frame rate:640X480 @ 30fps MJPEG,1280X720 @ 30fps MJPEG,1920X1080 @ 30fps MJPEG

YUV2,640X480 @ 20fps YUV2,1280X720 @ 5fps YUV2,1920X1080 @ 5fps YUV2

Signal to noise ratio: 60dB

Dynamic range: 69dB

Sensitivity: 3.3V/lux-sec@550nm

Minimum illumination: 0.01LUX

Shutter type: Electronic rolling Frame shutter/ exposure

Interface type: USB2.0 High Speed

Support free flooding protocol: USB Video Class (UVC)

Support OTG protocol: USB2.0 OTG

Automatic exposure control AEC: support

Automatic white balance AEB: support

Automatic gain control AGC: support

Adjustable parameters: brightness contrast color saturation hue resolution

The gamma exposure contrast gain white balance backlighting

Power supply: USB BUS 4P-2.0mm POWER socket

Working voltage: DC5V

Working current: 140mA~220mA

Working temperature: 0 ~ 60

Storage temperature: -20 ~ 70 C

Board size: 15X15mm

Machine weight: 50g

Supported system: WinXP/Vista/Win7/Win8/Linux with UVC (above linux-2.6.26)/MAC-OS X 10.4.8 or later

/Wince with UVC/Android 4 or with above UVC

Lens: 1.7MM

Angle: 160degrees

Line length:3M Cable Default

Real case:

Package contents:

1 x Camera
