Name: 5MP 35MM 25MM Lens Full HD 1080P 4K 8MP UVC OTG Type-C Android USB Camera Module 30FPS High Speed 2MP CCTV Webcam Support Audio
Brand: Mini USB Camera Mini Camera IP Camera Camhi Camera Factory
SKU: 3256805974860442
Price: 32.90 USD
Availability: InStock

Description

5MP 35MM 25MM Lens Full HD 1080P 4K 8MP UVC OTG Type-C Android USB Camera Module 30FPS High Speed 2MP CCTV Webcam Support Audio

Note:1080P/8MP USB2.0 Cable length 2meters default,TYPE-C 1meters

NOTE: Before purchasing this camera, please confirm whether your phone supports OTG function to avoid unnecessary losses

(For those who require OTG Micro USB interface, please contact customer service or note in your order,Thank you !)

Note:This Camera not apply to all the Android Phone and Computer System.PLS make sure your phone support otg function and UVC ,

The compatible Phone and Computer System please refer to the following list :Please note that your phone must support OTG and UVC camera function, Android system above.

Statement:The Mini product is only used for small space equipment. Forbidden To Be Used For Personal Eavesdropping And Taking Pictures.

Product Feature:

* FHD 1080P/8mp Mini USB Camera

* 1.66mm fisheye Lens

* Type C /OTG Micro USBinterface

* OTG support,UVC compliance for use in OS Windows,Linux,Androdi,Mac

Main Features:
Mini web camera, usb plug and play camera
Full hd 720P/ 1080P high quality image mini camera
Wire length: 2 meters
3.6mm prime lens Angle: approximately 90 degrees
3.7mm prime lens Angle: about 90 degrees
Drive: Drive free
USB port: USB 2.0 (type-c and Micro port optional)
1MP frame rate: 30fps
2MP Frame rate: 30fps
8MP frame rate: 15fps
Camera length and width: 15*15mm
Audio: 2MP 8MP Built-in microphone, 1MP does not support microphone

Product Description:

Sensor: So ny IMX179

Lens Size: 1/3.2inch

Pixel size: 1.4um

Image area: 6.18mm x 5.85mm

The most effective pixel: 3264(H) X 2448(V) 800MP pixels

Output image format: MJPEG

Supported resolution and frame rate:

3264X2448 @ 15fps / 2592X1944@ 15fps

1920x1080 @ 30fps / 1600X1200@ 30fps

1280X720 @ 30fps / 960X540@ 30fps

848X480 @ 30fps / 640X480@ 30fps
424X240 @ 30fps / 320X180 @30fps

Signal to noise ratio: 34dB

Dynamic range: 72.5dB

Sensitivity: 0.65V/lux-sec@550nm

Minimum illumination: 0.5lux

Shutter type: Electronic rolling shutter / Frame exposure

Interface type: USB2.0 High Speed

Support free drive protocol: USB Video Class (UVC)

Support OTG protocol: USB2.0 OTG

Automatic exposure control AEC: Support

Automatic white balance AEB: Support

Automatic gain control AGC: support

Button camera: support

Adjustable parameters: brightness, contrast, color saturation, hue, clarity

Lens parameters: with no distortion lens

Power supply mode: USB BUS POWER 4P-2.0mm socket

Working voltage: DC 5V

Working current: 160mA~260mA

Working temperature: -10～70℃

Supported systems:

WinXP/Vista/Win7/Win8

Linux with UVC (above linux-2.6.26)

MAC-OS X 10.4.8 or later

Wince with UVC

Android 4.0 or above with UVC

Optional lens is as follows, please write to me if you need it

Package contents:

1 x Camera 1 x English User Manual

Package contents:

1 x Camera 1 x English User Manual
