Name: 4K 8MP HD IMX415 3G 4G Sim Card IP Camera DC12V Battery Audio Video Surveillance Home GSM Security Wireless Camera CamHi P2P
Brand: Mini USB Camera Mini Camera IP Camera Camhi Camera Factory
SKU: GS-AHX4GCA8M-BQB
Price: 85.00 USD
Availability: InStock
Rating: 5 (1 reviews)

Description

4K 8MP HD IMX415 3G 4G Sim Card IP Camera DC12V Battery Audio Video Surveillance Home GSM Security Wireless Camera CamHi P2P

NOTICE:

Please read carefully before ordering

Pictures in Description just show Product Color, Product Shape, and Product Exterior, Some Accessories and Parts by default are Not demonstrated in the picture.
This is an industrial-grade HD camera. It is compatible with most of the monitoring system. Very easy to use. Even if you have any questions, you can get a reply within 24 hours.
If you need to buy more. But no suitable mode of transport for you to choose. Or transportation costs are too high. Please contact us. We will find a suitable way for you.
After you receive the goods. If there are any problems. Please contact us. We will help you solve the problem. If you are satisfied with our products. Please give us 5 star feedback.
Note: our product is support Wifi/3G/4G Wireless connect, not support wired connect(RJ45 port not work), but we support customized product, if you want RJ45 port, you can leave message for us.

Intelligent charging pile

3C product

Industrial router

Acquisition equipment

Handheld law enforcement terminal

Citroen connect

Smart Home

Intelligent Industry Control

Public bicycle

Intelligent express cabinet

Self-help terminal equipment

Security industry (video surveillance)

Application field:

Can support 8 users accessing WIFI hotspots

4G wireless transmission rate up to 150Mbps

Support 4G/3G/2G+Wi-Fi wireless access

Industrial 4G module

if you have other requirement ,welcome contact with us free !

Wireless WIF couplet

USB couplet (need drive support)

Connection mode:

5. Chip burn, no warranty

4.12V power interface, positive and negative pole should not connect in a wrong way

3. The USB interface is similar to the NIC interface, so please follow the illustration,so as not to burn down the settings

2. Please wiring in order

1. Wear anti-static bracelet or gloves before work

Matters needing attention:

Password:1234567890

AP hot name:MIFI_XXXX

Password:admin

User name:admin

How to quickly set up 3G/4G

First of all , Download APP "CamHi" from the iPhone App Store or Google Play Store. Or scan the QR code

If you choose the camera has 3G/4G. Then when the camera leaves the factory. The default connection to the 3G/4G module (signal MIFI-XX) has been set.

Note:If you use the reset button. Then you need to re-bind the camera to MIFI-xx

You only need a few simple steps.

Insert the SIM card into the camera. Connect the power adapter , wait 10-20s, camera will be ready.

Then open your phone WLAN setting , you will find "MIFI-XXX" and select to connect, the default password is 1234567890

When your phone is connected to MIFI-XX. Then open the app "camhi". Select "Add Camera."

Because your phone is connected to MIFI-XX. So you can choose "Search Camera from LAN". Or directly scan the QR code of the camera.

Then you can see your camera online. You can control the camera and watch videos from your phone.

NOTE:

If view the 3G/4G camera is offline, please check the SIM card”.

Use the mobile phone or PC to connect the WIFI “MIFI_3F41”,the WIFI password is “1234567890”, you can find the WIFI when the

camera starts working. Access “192.168.100.1” through the browser, the page password

is “admin”, you can check the SIM card information on this page.

If your camera display is offline, please note the following:

1.Damaged card or wrong installation direction when prompted "

No SIM Card or SIM Card invalid! ", as shown below:

2.Frequency not supported or SIM card arrears when prompted "No Service" or "Limited Service", as shown below 1):

3.Make sure 3G/4G signal strength is enough, as shown below 2):

1. Features

8.0 megapixel HD 3G/4G IP camera, maximum resolution 2560x1920;

Support 4G, support AP mode;

Support up to 128G TF card storage;

Built-in MIC and speakers

Support P2P, view & anywhere & anytime;

Elegant outline and easy installation;

Provide android & ios APP and professional CMS PC client software;

2. Specifications

Model		GS-AHX4GCA8M-BQB
Video	Sensor	8.0 megapixel1/2.8" SONYIMX415
	Video resolution	Main stream: 3840x2160@20FPS, Sub stream: 1280x720@25fps,
	Videocompression	H.264/H.265
	Lens	3.6mm button lens
	View angle	92degree
	Night vision	not support
Audio	Audio compression	G.726/G.711
	Audio code rate	8Kbps, 16bit
	Audio input	Built-in MIC and speakers, support one way
Audio	Audio compression	G.726/G.711
	Audio code rate	Rate adaptive
	Audio input	Support
	Audiooutput	optional
Alarm	Motion detectingalarm	Can set4independentdetection region(1-100 sensitivitycan be set)
	Alarm linkage	Alarmsend picturesto the mailbox, Alarmupload pictures and videos to theFTPserver, Alarm recordpictures and videos toMicro SD card, Alarm mobile phone message push
	Alarm recording	Support Micro SD cardand PC client linkage alarm recording
4G	4Gstandard	FDD-LTE/TDD-LTE
	4G frequency range	B1(2100MHz), B3(1800MHz), B7(2600MHz), B8(900MHz), B20(800MHz), B38(2600MHz), B40(2300MHz), B41(2500MHz)
	Interface type	Micro SIMcard, Plug and play, no need to set
Storage	Micro SD card	Supportup to128Gmicro SD card
	Recording mode	Alarm record, timing record,
	Video playback	Support APP, IE browser, remote clientplay and download the video
PTZ	Rotation angle	/
	Horizontal speed	/
	Vertical speed	/
		/
General specification	Power	DC12V 1A
	Operatingenvironment	Environment-20℃~+60℃
